Presenter tracking
- Either track full body or half body.
- Shield Zone avoids selected areas within the effective tracking area to avoid busy spaces.
- Simple click to track and manually follow an additional presenter via remote control or Web UI.
![Presenter tracking](../../images-aver/products/tr535n/fea-people-tracking.jpg)
Voice tracking
AVer PTZ cameras and select compatible microphones for precise voice tracking using the camera preset points. Run PTZ Link software on in-room UC compute or PC or integrate MT300N for worry free security and OS updates. No need for costly programmers.
![Voice tracking](../../images-aver/products/tr535n/fea-voice-tracking.jpg)
Other Tracking Modes
- Segment Tracking: Create four zones on multiple displays for instant content recognition, keeping the focus on the content, not the presenter.
- Zone Tracking: Preset zones enhance content-focused video capture across multiple displays.
- Hybrid Tracking: The camera auto-switches between Presenter and Zone modes, combining the best features of both for flexible tracking.
![Other tracking mode](../../images-aver/products/tr535n/fea-hybrid-mode.jpg)
4Kp60
The TR535N can stream in 4K at 60 fps through HDMI, USB, and IP outputs. With simplified setups and without the hassle of tangled cables, you can seamlessly utilize multiple devices at once to create smooth video streams.
Flexible Mounting Options
The TR535N brand new dual camera design with tiltable secondary lens allows for flexible installation options, including wall and ceiling mounts.
![Flexible Mount Installation](../../images-aver/products/tr535n/flexible-mounting.jpg)
NDI® High Bandwidth for Ultra-low Latency
Access unparalleled streaming excellence with the TR535N's NDI® High Bandwidth technology. Experience the almost lossless compression, ultra-low latency, and pristine image quality that simplify even the most intricate setups, effortlessly redefining the landscape of modern video content sharing and production.![NDI® High Bandwidth for Ultra-lowLatency](../../images-aver/products/tr535n/fea-ndi-high-bandwidth-for-ultra-low-latency.png)
Compatible software
Microsoft Team
Barco
Q-Sys
Crestron
Echo360
Extron
KALTURA
Panopto
vMix
ZOOM
Telestream
Newtek
Free Software for Users and AV Managers
Whether you need a simple tool to control your PTZ or TR camera, or manage over a hundred on your network, AVer has great options. CaptureShare and PTZ Management for desktop and AVer PTZ Control Panel for iPad have you covered. For new voice tracking features, look to PTZ Link. Visit our support page for easy download of our desktop software.
![CaptureShare & AVer PTZ Management & PTZ Control Panel & PTZ Link](../../images-aver/products/pro-av/captureshare-ptz-management-ptz-control-panel-ptz-link.png)
Enjoy the unprecedented quality and support
AVerCare delivers industry-leading 5 or 3 year* warranty with Advanced Replacement and 24-hour turnaround time in the first year. We strive to provide industry leading product quality, service and support so you’re always up and running!
* 5-year protection is included only on “V2” and the newest Pro AV cameras, and the MT300N as of August 16, 2023. Optional 2-year extended warranty is available for purchase on 3-year warranty covered products only.
![AVerCare](../../images-aver/products/pro-av/avercare-5yr.png)
Specifications
Front
![Front](../../images-aver/products/tr535n/ptz-front.png)
Back
![Back](../../images-aver/products/tr535n/ptz-back.png)
Camera
Image sensor | Pixel | Output resolution |
---|---|---|
1/2.8" CMOS | 8 megapixels | Resolution: 4k*/1080p/720p Frame Rate : 60/59.94/50/30/29.97/25 |
TV line | Focal length | Iris |
1600 (center/wide) | f = 4.5 ~ 135 mm | F = 1.8 (Wide) ~ 4.7 (Tele) |
Optical zoom | Digital zoom | Total zoom |
30X | 1X | 30X |
D FOV | H FOV | V FOV |
69.2° (wide) ~ 2.8°(Tele) | 62.3° (wide) ~ 2.5°(Tele) | 37.3° (wide) ~ 1.4°(Tele) |
Minimum illumination | Minimum working distance | Focus |
0.5 lux (IRE50, F1.6, 30fps) | Wide 0.1m, Tele 1.2m | Auto/Manual/One Push |
White balance | Gain | Shutter speed |
Auto | Auto /Manual | 1/1 s to 1/10,000 s |
BLC (Back Light Compensation) | Exposure | Noise reduction |
Yes | Auto, Manual, Priority AE( Shutter, IRIS), BLC, WDR | 2D/3D NR |
Frequency | S/N ratio | Image effect |
50Hz & 60Hz | ≥50dB | Mirror/ Flip Freeze / WDR / BLC |
WDR (Wide Dynamic Range) | ||
Yes |
Pan tilt parameter
Pan rotation | Tilt rotation | Pan control speed |
---|---|---|
-170°~+170° | -30°~+90° | 0.1 ~ 100°/Sec |
Tilt control speed | Preset speed | Preset number |
0.1 ~ 100°/Sec | Pan : 200°/Sec, Tilt : 200°/Sec | 10 Locations by Remote, 256 vis RS232 |
IP streaming
Resolution (Max) | Video compression | Audio compression |
---|---|---|
4K (60PFS) | H.264, H.265, MJPEG | AAC-LC (48 K) |
Protocol | Bitrate | Bitrate control mode |
IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, DHCP, RTP / RTCP, RTSP, RTMP, SRT, HLS, NDI, LLDP, VISCA over IP | 512Kbps ~ 64Mbps | VBR/CBR (selectable) |
Multi-stream capability | ||
10, 4K 60fps: RTSP (x2), HDMI (x2), USB (x2), NDI® High Bandwidth (x1), & NDI® HX2 (x2), *3G-SDI only support 1080p60 |
I/O interface
Video output | Audio output | Audio input |
---|---|---|
3G-SDI, HDMI x 2, IP, USB | 3G-SDI, HDMI x 2, IP, USB | MIC in/Line in |
Baud rate | Control interface | Control protocol |
n/a | RS-232/RS-422, IP, USB | VISCA/PELCO-D (RS232/RS422), CGI (IP), USB, ONVIF |
Network interface | USB | POE+ |
10/100/1000 Base - T | 3.2 | PoE++ |
Power requirements | ||
AC 100 - 240V to DC 12V/5A |
USB
Connector | Video format | Resolution (Max) |
---|---|---|
USB 3.2 Gen 1 | MJPEG, YUY2 | 2160P |
Video class | Audio class | |
UVC 1.1 | UAC 1.0 |
Audio
Channel | Codec | Sample rate |
---|---|---|
2ch (stereo) | AAC-LC(48K) | 48Khz |
System
IR remote control | Tally | Power consumption |
---|---|---|
Yes | Yes | 29W |
Operating temperature | Operating humidity | Storage temperature |
0°C ~ +40°C | 20%~80% | -20°C ~ +60°C |
Storage humidity | Dimensions | Net Weight |
20% ~ 95% | W202.5*D250.7*Hx 218.5mm | 3.6 kg (+/-0.1) (7.9 lbs) |
Kensington Lock | Application | |
Yes | Indoor | |
Accessory | Optional Accessories | |
Camera, Remote Control, RS-232 In/Out Cable, Din 8 To D-Sub 9 Cable, Power Adapter, Power Cord, Cable Tie (x7), M2 x 4 mm Screw (x5), M3 x 6 mm Screw (x3), 1/4"-20L 6.5 mm Screw (x2), Cable Fixing Plate (x2), Ceiling Mount Bracket (x2), Drilling Paper, Quick Start Guide | L-Type Wall Mount, Camera Controller(CL01) |
Warranty
Camera | Accessories | |
---|---|---|
5 Year | 1 Year |
Tracking
Mode | NDI | |
---|---|---|
Presenter, Zone, Hybrid, Segment | NDI® High Bandwidth |
Ordering info
Part number | ||
---|---|---|
PAT535NV3 |
Package contents
Camera
SKU: PAT335NV3Drilling Paper
Ceiling Mount Brackets
SKU: PTMLTCM01 Install GuideQuick Guide
Cable Fixing Plate
M2 x 4mm Screw (x3)
Power Adapter & Power Cord
6.5mm Screw (x2)
Remote Control
M3 x 6mm Screw (x3)
DIN8 to D-Sub9 Cable
SKU: PTDIN8PT1RS-232 In/Out Y Cable
SKU: PTRSINOUTCable Tie (x4)
Optional accessories
Wall Mount Bracket
SKU: PTMLTWM03 Install GuideCL01 Camera Controller
SKU: PTCAMCTRLHDMI to USB converter
SKU: PTCVBU110 Datasheet
