4K
Output13MP
Camera23x
Digital zoom3Yr
WarrantyP2P
Wi-Fi
![Tech & Learning Award Excellence 2019](../../images-aver/awards/award-tech-learning-award-excellence2019.png)
Connect wirelessly with
Peer-to-Peer WiFi
With the Peer-to-Peer (P2P) Wi-Fi technology, the M15W creates a direct Wi-Fi connection to your computer. This dedicated connection ensures maximum performance and reliability without interfering with your existing school or work Wi-Fi or Ethernet connection(s).
Connect your way!
The M15W includes an on-board battery and Wi-Fi connectivity to allow complete freedom to move and share around the classroom. Multiple wired connection options such as HDMI and USB provide additional flexibility for many device types.
![Connect your way!](../../images-aver/products/m15w/feature-connect-your-way-2.png)
Amazing clarity and coverage
Showcase vivid details in your presentation and create a captivating experience with the document camera's 4K output at 60 fps and 23x digital zoom features. The massive 16.77” × 12.32” shooting area allows you to capture and share large documents and objects like never before!
![Lights](../../images-aver/products/m15w/feature-amazing-clarity-lights.png)
![Amazing clarity and coverage](../../images-aver/products/m15w/feature-amazing-clarity-1.jpg)
![Amazing clarity and coverage](../../images-aver/products/m15w/feature-amazing-clarity-1-sm.jpg)
![](../../images-aver/products/m15w/camera-sequence-1.png)
Hybrid learning ready
Want to stream and share your lessons? The high definition resolution with built-in microphone supports integration with popular video conferencing applications, while the compact design and rotating camera head allows you to place and point the camera anywhere in the room.
![AVerTouch](../../images-aver/products/m15w/aver-touch-icon.jpg)
Software is as simple as one touch
With the AVerTouch software it’s never been quicker and easier to go from set-up to showtime. Build and edit new creative content with powerful multitasking and editing tools and save to the cloud with a simple click.
![](../../images-aver/products/m15w/m15w-5.png)
Extremely compact design
With its fully collapsible and compact design, the M15W document camera is perfect for space-constrained classrooms. Easily store or transport it to anywhere in a school.
Specifications
Sensor1/3.06” VCM | Pixel count13 megapixels |
---|---|
ZoomingTotal 23X maximum | Shooting area426mm x 313mm @330 mm |
Specifications | |||||
---|---|---|---|---|---|
Sensor | 1/3.06" VCM | Pixel count | 13 megapixels | ||
Frame rate | 60 fps (max.) | Image mode | Normal/ High Frame/ High Quality | Effect | Rotate/ Freeze |
HDMI output | 4K; HD 1080p 60Hz; HD 720p 60Hz | Focusing | Auto/ Manual/ Area (SW) | Shooting area | 426mmx313mm @ 330 mm |
Zooming | Total 23X maximum | Dual mode | AP / Station DHCP (Server/ Client) |
WiFi streaming | 1080P@30fps, up to 4K@30fps |
Dual band | 5GHz recommended | P2P | Yes | Miracast | Yes |
Compatibility | 802.11a/b/g/n/ac (45 ft effective range) | Wireless security | Support WEP, WPA/WPA2-PSK, WPA/WPA2-Enterprise* *EAP-PEAP, EAP-TLS | Power source | DC5V/ 2A, AC 100-240V |
Consumption | 4 Watts (lamp on) 3.5 Watts (lamp off) |
USB bus power | Yes (standby mode only) | Lamp type | LED light |
USB | USB2.0 Type-A (WiFi Dongle) USB Type mini-Bx1 | DC 5V input | Power jack | MIC | Built-in |
Operating | 518mm(L)* 84 mm(W)* 351mm(H) (+/-2mm include rubber foot) |
Folded | 280mm(L)* 84mm(W)* 42mm(H) (+/-2mm include rubber foot) | Weight | 1.4 kg (about 3.1 lbs) |
Software supported | ePTZ, Image/ Area capture, Picture by Picture, Timer, Cloud library, Recording, Annotation |
Package contents | |||||
---|---|---|---|---|---|
M15W | |||||
Wi-Fi dongle | |||||
USB cable (Mini type) | |||||
Power adapter/ Power plug | |||||
Instruction manual |
Optional accessories | |||||
---|---|---|---|---|---|
Carrying bag | Part number: VISIOCPCC | Anti-glare sheet | Part number: PANTIGLA1 (A5 size 8.26" x 5.84") | Power adapter | Part number: PPDC5V3PA |
P2P USB WiFi Dongle | Part number: PPDWIFIDG |
Warranty |
---|
3 year warranty All AVerVision accessories : 1 year warranty (rechargeable battery: 1 year warranty) |
Others | |||||
---|---|---|---|---|---|
Ordering Info | SKU: VSIONM15W |
Note: Specifications subject to change without notice
