5
Mega Pixel30
FPS16x
Digital Zoom
Full 1080p with 5MP Sensor
With the 300AFHD document camera's full 1080p HDMI output, you are now able to connect your document camera to HDMI displays and HDMI capable projectors, allowing you to see the HD image quality you were meant to see.
Quick Auto-Focus & 16x zoom
The 300AFHD document camera's 5MP, 16x zoom and one-touch auto focus combine to provide unsurpassed image quality with stunning detail in the shortest amount of time.
Embedded LED light module
Usually when the projector is on, the lights are off. However, since the 300AFHD document camera is connected to a projector, it has a built-in LED light in the camera head to illuminate and display any object under the camera with ease.
The AVer Document Camera has been the best teaching tool I have ever used. I have no regrets about getting the document camera instead of an interactive white board. The document camera has so many more functions and uses than I ever imagined.Broadneck Elementary School | Read Case Studies
Specifications
| Sensor1/3" CMOS | Pixel Count5 megapixels |
|---|---|
| Zooming16X Digital Zoom | Shooting AreaMax. 13.66" x 10.28" (337mm x 261mm) |
| Image | |||||
|---|---|---|---|---|---|
| Sensor | 1/3" CMOS | Pixel Count | 5 megapixels | Frame Rate | 30 fps (max.) |
| White Balance | Auto / Manual | Exposure | Auto / Manual | Image Mode | Sharp / Graphics / Motion / Microscope |
| Effect | Color / B/W / Negative / Mirror / Rotate / Freeze | RGB Output | 1920x1080, 1280x720, 1280x1024, 1280x800, 1600x1200, 1024x768 | HDMI Output | 1920x1080, 1280x720 |
| Optics | |||||
|---|---|---|---|---|---|
| Focus | Auto / Manual | Shooting Area | Max. 13.66" x 10.28" (337mm x 261mm) | Zooming | 16X Digital Zoom |
| Function | |||||
|---|---|---|---|---|---|
| Image Effect | Color / B&W / Negative / Mirror / Reverse / Freeze | White balance / exposure | Auto / Manual | Picture-in-picture | Yes |
| Presentation Tools | Spotlight (Yes), Visor (Yes) | Capture Mode | Single / Continuous | Remote Control | Yes |
| Image Storage | 240 Frames (XGA); 80 Frames (5M Pixel) | Onboard AV Recording | Yes, SD/SDHC/USB | Onboard Annotation | Yes, works with any HID device (eg. USB Mouse) |
| Compatibility | |||||
|---|---|---|---|---|---|
| Operating Systems | Windows 7 (32/64 bit), Windows 8 (32/64 bit), Windows 10 (32/64 bit), Mac OS X 10.9 or above (Intel based), Chrome OS 29 or above | AVer Software | AVer A+ Software Suite (Sphere 2, PowerPoint Plug-in, Flash-Plug-in), Sphere Lite (for Chromebook) | Interactive Whiteboard Compatibility | Yes with AVerVision Flash Plug-in *certain limitations apply |
| Power | |||||
|---|---|---|---|---|---|
| Power Source | DC 12V, 2A, 100-240V, 50-60Hz | Consumption | 10.8 Watts (lamp off); 12 Watts (lamp on) | ||
| Lighting | |||||
|---|---|---|---|---|---|
| Lamp Type | LED light | ||||
| Dimension | |||||
|---|---|---|---|---|---|
| Operating | 14.68" x 6.85" x 21.34" 373mm x 174mm x 542mm (+/-2mm include rubber foot) | Folded | 14.45" x 6.85" x 3.89" 367mm x 174mm x 99mm (+/-2mm include rubber foot) | Weight | 4.4 lbs (2kg) |
| External Storage | |||||
|---|---|---|---|---|---|
| Secure Digital (SDHC) | 1GB ~ 32GB (FAT32) | USB Flash Drive | 2GB ~ 64GB (FAT32) | ||
| Optional Accessories, eStore | |||||
|---|---|---|---|---|---|
| Microscope Adapter | Part number: VISIONNMA | Anti-Glare sheet | Part number: PANTIGLA1 (A5 size 8.26" x 5.84") | Carrying Bag | Part number: VISIONPCC |
| Package Contents | |||||
|---|---|---|---|---|---|
| 300AFHD | |||||
| 3´ USB Cable (Mini Type) | |||||
| RGB Cable | |||||
| Power Adapter 12V/2A | |||||
| Remote Control (including batteries) | |||||
| Quick Guide |
